Zefyr · Golf Cart Series
Zefyr Z22
2+2 Seat Electric Golf Cart
Designed for smooth, quiet performance across courses, resorts, and private communities. The Zefyr Z22 delivers reliable electric power with a rugged frame built for daily use.
Key Specs
- Seating4 Passengers
- Motor5KW AC Motor
- Battery51.2V 105Ah LiFePO₄ Battery
- Range40 miles
- Max Speed19 mph
- Charging8–10 hours
| Controller | 350A Intelligent Electronic Controller |
|---|---|
| Charger | Intelligent Charger (110V / 220V) |
| Overall Dimensions | 2750 × 1350 × 2050 mm |
| Wheelbase | 1690 mm |
| Track Width | Front 890 mm / Rear 990 mm |
| Ground Clearance | 180 mm |
| Curb Weight | 992 lbs |
| Load Capacity | 1323 lbs |
| Turning Radius | 13.1 ft (4 m) |
| Climbing Capacity | 20% |
